by Ultra Base Systems Verified company
Photo credit: Ultra Base Systems
Surface typeModular interlocking base panel
Total thickness0.75 in
InterlockingSame interlocking technology as the Professional panel
Warranty10 years
About this product
A thinner 3/4 inch version of the Professional panel, using the same interlocking technology. It is a more flexible and cost-effective sub base for artificial turf in landscapes, athletic fields and golf applications.
Best for
Sports
SoccerFootballBaseballFacility types
FieldSpecifications
Mounting and size
Weight6 lbs per panel (1.38 lbs per sq ft)
Infill and safety
Gmax119
Drainage rate1,582 in/hr vertical; 126 in/hr horizontal
Surface system
Surface typeModular interlocking base panel
Total thickness0.75 in
Tile size30 x 30 in (28 x 28 in, 5.44 sq ft, once installed)
InterlockingSame interlocking technology as the Professional panel
Other details
Load capacityexceeds 370 psi
Storage capacity1.85 gallons
Certifications and warranty
Warranty10 years
Source: company website · View the source → · Last verified Oct 8, 2026
